HDMI MATRIX 8 x 8 Seamless with video wall

Technical
HDMI Compliance	HDMI 2.0
HDCP Compliance	HDCP 2.2
Bandwidth	18Gbps
Video Resolution
Input	800×600@60Hz, 1024×768@60Hz, 1280×768@60Hz, 1280×800@60Hz, 1280×1024@60Hz, 1360×768@60Hz, 1366×768@60Hz, 1400×1050@60Hz, 1440×900@60Hz, 1600×1200@60Hz, 1680×1050@60Hz, 1920×1200@60Hz, 480p, 576p, 720p, 1920x1080i, 1920x1080p, 3840×2160@24Hz/25Hz/30Hz/50Hz/60Hz, 4096×2160@24Hz/25Hz/30Hz/50Hz/60Hz
Output	1920×1080@60Hz, 3840×2160@30Hz, 3840×2160@60Hz,, 1280×720@60Hz, 1024×768@60Hz, 1360×768@60Hz, 1600×1200@60Hz, 1920×1200@60Hz
HDMI Amplitude	T.M.D.S +/- 0.4Vpp
Differential Impedance	100±15ohm
ESD Protection	Human body model – ±8kV (Air-gap discharge) & ±4kV (Contact discharge)
RS232 / Ethernet Control
Baud rate and Protocol	Baud rate: 9600, Data bit: 8 Stop bit: 1, no parity checking
Ethernet	IE10.0+, HTML5
Mechanical
Housing	Metal Enclosure
Color	Black
Dimensions	430mm (W) x 300mm (D) x 44mm (H)
Weight	5Kg
Power Supply	AC 100 ~ 240V
Power Consumption	100W (Max)
Operating Temperature	0°C ~ 40°C / 32°F ~ 104°F
Storage Temperature	-20°C ~ 70°C / -4°F ~ 158°F
Relative Humidity	10 ~ 50% RH (non-condensing)
